Dubai, UAE / Dubai

We at Elite Property Commercial Brokers present to you a complete disassembled crude oil refinery. This refinery is sealed, packed, and stored near the Jebel Ali Freezone Port and is ready to be uploaded and shipped to your required destination.

OVERVIEW

Crude Oil Refinery 15000BPD
The refinery is American industrial Certified by .
Built by Armco company
The operating time was 3 months only.
The former licensee was Aramco Company.
Refinery Capacity In Regular crude oil is (15000)BPD .
Refinery Capacity In Heavy crude oil is (13000)BPD .

End products of refinery:
Diesel - naphtha - gas - fuel oil.
The oil refineries processed mainly heavy to medium crude oils in the range of API 23.7 - 34 with Sulphur contents of 2.0 - 3.63)
According to US safety standards, the refinery is designed specifically for Aramco company.

Also according to American high standards:
The refinery designed:
All refinery equipment treatment, corrosion, sulfur and rust.
All refinery equipment Designed to withstand at a very high temperature.
According to environmental specification and environmental protection:
The Flare designed to produce 0% pollution.

Note that the main furnace has a capacity of 32,000,000 calories and works on fuel. It is designed to refine 25,000 barrels per day of heavy crude oil. Therefore, a simple modification in the cooling devices, as well as in raising the capacity of the push pumps for the raw materials.

ARTICLE 01 ~ REFINERY MACHINERY, CAPACITY & SPECS
THE REFINERY CONSIST OF THE FOLLOWING MAIN MACHINERY AND EQUIPMENT WITH THE MENTIONED CAPACITIES AGAINST EACH MACHINERY

REFINERY UNIT CAPACITY BARREL PER DAY

NO 1 CRUDE DISTILLATION UNIT 20,000
NO 1 VACUUM DISTILLATION UNIT 6,000
NO 2 VACUUM DISTILLATION UNIT 5,000
NO 1 SATURATE GAS PLANT (REFORMER) 5,355
NO1 LSR GASOLINE MEROX & LPG ABSORBER 1,095
NO. 1 NAPHTHA UNIFIER UNIT 2,410
NO.1 PLATFORMER 5,660
NO.1 HYDROCRACKER ISOMAX 6,320
NO. 1 HYDROGEN PLANT, NM3/HR 18,478
NO.1 ASPHALT OXIDIZER 500
NO 2 ASPHALT OXIDIZER 3,600
NO. 1 AMINE UNIT, NM3/H 2,960
NO. 1 WASTE WATER STRIPPER 857
NO 1 VISBREAKER (IDEL) 2,805
NO 2 ELECTRICAL GENERATORS 12.5 MIGA
PIPING MORE THAN ¼ INCH DIA MIGA AS PER P&ID

SPECIFICATIONS: DETAILED MACHINERY SPECS IS AS PER UOP SCHEDULE A, AND IS AVAILABLE IN MANUALS AND CATALOGS READY WITH THE MACHINERY OWNER RPPC. PIPING AND LAYOUTS DRAWING ARE AVAILABLE WITH RPPC.

*A FULL IN-DEPTH PRODUCT AND EQUIPMENT FILE WILL BE PROVIDED ON REQUEST
